54 Energy - Renewable Energy Store

Solar Controller 80A Solar Charger Battery 12V/24V/48V 36V setting Charger Max 150VDC Back-light LCD Solar Regulator

Solar Controller 80A Solar Charger Battery 12V/24V/48V 36V setting Charger Max 150VDC Back-light LCD Solar Regulator

Regular price $372.93
Regular price Sale price $372.93
Sale Sold out
Tax included. Shipping calculated at checkout.
Ships From

SPECIFICATIONS

  • Is_customized: Yes
  • Usage D: MPPT solar charge controller
  • Usage C: solar controller 80A
  • Usage B: solar battery charge controller MPPT
  • Usage A: controlador solar 80A
  • Model Number: IChanger mppt 80A
  • Maximum Current: 80A
  • Is Smart Device: Yes
  • Function2: regulador solar MPPT
  • Function 1: solar regulator 80A MPPT
  • Function: solar regulator 80A MPPT
  • Feature 2: SCC-MPPT-3KW
  • Feature: solar charge controller 80A
  • Description 2: controlador solar MPPT
  • Description 1: regulador solar 80A
  • Description: regulador solar 40A 80A
  • Application: Charger Controller,Solar System Controller,Solar Working Station



Feature:

  • 80A MPPT solar charge controller(Fan cooling)

  • 12V/24V/48V (auto detection);36V(setting)

  • MPPT efficiency>99%,Peak conversion

  • efficiency >98%

  • DSP processors technology ensure high

  • speed and performance

  • Multi-stage charging mode

  • Protection: PV array short circuit ,

  • PV reverse polarity , Battery reverse polarity ,

  • Over charging , Output short circuit

  • Equalization charging function

  • BTS function

MODEL

IChargerMPPT-4880

NominalBatterySystemVoltage

12V\24V\48VDC(Autodetection);36V(Setting)

CONTROLLERINPUT

BatteryVoltage

12V

24V

36V

48V

MaximumSolarInputVoltage

100V

145V

PVArrayMPPT VoltageRange

15~95V

30~130V

45~130V

60~130V

MaximumInputPower

12Volt-1250W/24Volt-2500W/36Volt-3750W/48Volt-5000W






BATTERY

ChargingSetPoints

AbsorptionStage

FloatStage

FloodedBattery

14.2V\28.4V\42.6V\56.8V

13.7V\27.4V\41.1V\54.8V

AGM(Default)

14.4V\28.8V\43.2V\57.6V

13.7V\27.4V\41.1V\54.8V

Over-chargingVoltage

15.5V\30.0V\45.0V\60.0V

Over-chargingComebackVoltage

14.5V\29.5V\44.5V\59.0V

BatteryDefectVoltage

10.0V\17.0V\25.5V\34.0V

TemperatureCompensation

Conefficient

-5mv\℃\cell(25℃vef)

PeakConversionEfficiency

98%(MPPTEfficiency99%)

MximumBatteryCurrent

80Amps

MaxChargingCurrent

80ampscontinuous@40℃ambient

GENERAL

SPECIFICATION

RadiatingMode

Fancooling

DISPLAY

&PROTECTION

Protections

Solarhighvoltagedisconnect/Solarhighvoltagereconnect/Batteryhighvoltagedisconnect/Batteryhighvoltagereconnect/Hightemperaturedisconnect/High

temperaturereconnect

MECHANICALSPECIFICATIONS

Mounting

Wallmount

MachineDimension(W*H*D)

152*85*294mm(perpcs)

G.W(kg)

3kg/pcs

PackageDimension(W*H*D)

625*366*232mm(4pcs/Carton)

GrossWeight(kg)

14kg

OTHER

EnvironmentalRating

Indoor

OperationTemperatureRange

-10~55℃

AmbientHumidity

0~90%relativehumidity(non-condensing)

Altiude

≤3000m
