⚡ 2P DC 1000V MCB Solar Mini Circuit Breaker Overload Protection Switch 6A 10A 16A 20A 25A 32A 40A 50A 63A DC1000V Photovoltaic PV
Upgrade your system with our high-performance 2P DC 1000V MCB Solar Mini Circuit Breaker Overload Protection Switch 6A 10A 16A 20A 25A 32A 40A 50A 63A DC1000V Photovoltaic PV. Built for reliability, efficiency and seamless integration with modern setups.
📌 Key Benefits
- ✅ High-efficiency design for superior performance
- ✅ Optimized heat dissipation and durability
- ✅ Plug-and-play compatibility for easy integration
- ✅ Ideal for industrial and residential use
📄 Technical Specifications
As an expert in the field, you can trust the 2P DC 1000V MCB Solar Mini Circuit Breaker to provide reliable overload protection. With options ranging from 6A to 63A and a maximum voltage of 1000V, this breaker is perfect for photovoltaic applications. Keep your solar panels safe with this quality switch.
SPECIFICATIONS
- Brand Name: EARUELETRIC
- Type: Mini
- Type: Circuit breaker
- Model Number: EACBDC
- Pole number: 2P
- Breaking current: 4500
DC 1000V Solar Mini Circuit Breaker Overload Protection Switch 2P DC1000V Photovoltaic MCB PV
Our factory can offer OEM/ODM Service, if you need to circuit breaker with your logo, feel free to contact the seller!
Application
EACBDC-63 Series DC Miniature Circuit Breaker, apply to rating current 63A or less, Direct current rating voltage is 250V for 1 Pole. It is mainly used for the overloading and short circuit protection in DC distribution system Equipment and electric equipment. It can be widely used in electric, post, traffic, mining enterprise and different kinds of fields. In present China, our products in the case grade rating voltage is highest compared to the same products. Products according IEC60898-1, GB14048.2 standard.
Specificaatios
|
Standard |
EN60898(IEC60898) IEC60947-2 |
|
Rated current |
1-63A |
|
Rated Breaking capacity |
6.0kA IEC60898(0.5~63A) |
|
Characteristic curve |
B,C,D |
|
Max. fuse that can be connected to |
100AgL(>10kA) |
|
Selective grade |
3 |
|
Working ambient temperature |
-10℃ ~+40℃ |
|
Enclosed protective class |
IP20 |
|
Electrical life |
Not less than 8000 times |
|
Mechanical life |
Not less than 20000 times |
