TUYA WiFi Smart Thermostat Temperature Controller For Electric Floor Heating Water Gas Boiler Digital LCD Display Wall Mounted

Name: TUYA WiFi Smart Thermostat Temperature Controller For Electric Floor Heating Water Gas Boiler Digital LCD Display Wall Mounted
Rating: 5 (2 reviews)

TUYA WiFi Smart Thermostat Temperature Controller For Electric Floor Heating Water Gas Boiler Digital LCD Display Wall Mounted

$39.00 USD

~~$0.00 USD~~ $39.00 USD

En vente Épuisé

Frais d'expédition calculés à l'étape de paiement.

Color K5H16A K5RH3A WiFi-K5H16A WiFi-K5RH3A

Quantité

Efficiently control and monitor your home's heating with the TUYA WiFi Smart Thermostat. This wall-mounted device boasts a digital LCD display and is compatible with electric floor heating, water, and gas boilers. With its TUYA app integration, you can easily adjust and set precise temperatures for optimal comfort and energy savings. Enjoy a smarter, more comfortable home with this advanced thermostat.

SPECIFICATIONS

Temperature Sensor: NTC
Temperature Accuracy: ±1℃
Display: LCD
Working Environment: -5~50℃
Power Consumption: <1W
Temperature Setting: 5~60℃
Display Range: 0~50℃
Input Voltage: AC 90-240V
Load Current: Plumbing 3A(resistive),electric heating 16A 20A

Specification

Material:Anti-flammable PC
Voltage:AC 230V,50/60Hz
Max. Current Load: 3A/16A
Temperature Accuracy: ±1℃
Temperature Setting: 0-80℃
Item Size: 86 * 86 *mm/ 3.4 * 3.4in
Power Consumption:＜1W
Temperature Sensor:NTC

User Operation

Power on/off: Press key to turn on/off the thermostat
Press M key to switch between manual and automatic modes.
In automatic mode, press key or key to enter automatic temporary mode, which only runs for several minutes.
Press key to enter the clock setting, and press keys to adjust the value of each parameter.
Note: WiFI model will automatically obtain the Internet time.
The child lock is off by default at the factory. If you want to use this function, you need to enter the advanced option to enable the child lock function. Long press button for 5 seconds to temporarily turn off it.

Mode Description

＋floor heating manual mode
🕐+ floor heating automatic mode

Period Programming Instructions

In the power-off state, long press key M+🕐 key, then press M key to switch options, press 🔼 key or🔽 key to adjust the parameters, and press key to exit with saving.

Advanced Option Settings

In the power-off state, press M key and🔽 key simultaneously for 5 seconds to enter advanced option setting.
Press M key to enter the next option, press🔼key and🔽 key to adjust, and press key to exit advanced option.
