This pair of solar photovoltaic connectors is rated 1000 V DC and 30 A with IP67 waterproofing and an operating range from -40 °C to +85 °C, making them suitable for outdoor PV strings on rooftops, RVs, vans, boats, and off-grid solar setups. Tinned-copper contacts crimp onto 2.5 to 6 mm² solar cable, and the PPE housing is rated UL94-V0 for flame resistance.
Product Description
This is one matched pair (male + female) of solar photovoltaic connectors designed for series and parallel wiring of PV modules. The body is PPE plastic, the contact is tinned copper, and the assembled connector seals to IP67 against dust and immersion when properly crimped to a sized solar cable. The intended use is connecting solar panel output leads to MC4-compatible interconnects, charge controllers, and combiner boxes in residential rooftop, mobile (RV, boat, caravan), and off-grid installations.
Insertion and withdrawal forces are specified at ≤50 N and ≥50 N respectively, which is the standard handling envelope for PV connectors and ensures the joint will not back out under cable weight or thermal cycling. The connectors are intended to be crimped with a proper PV crimping tool — they are not solder-on, and the contact relies on cold-weld crimping for its current rating.
Key Benefits
- 1000 V DC / 30 A rating covers virtually all residential and small-commercial PV strings
- IP67 waterproof and dust-tight for rooftop and outdoor mobile installations
- Wide -40 °C to +85 °C operating range covers desert, alpine, and tropical climates
- UL94-V0 flame-rated PPE housing meets standard PV component fire safety
- Tinned copper contacts maintain low resistance over years of exposure
Key Features
The defining feature is the contact-and-housing pairing: tinned copper inside a UL94-V0 PPE shell. Tinned copper resists oxidation in humid and salt-air environments — important for boat, coastal, and rooftop installs — while UL94-V0 is the highest household flame-resistance rating, meaning the housing self-extinguishes within seconds and does not drip flaming material if exposed to a flame. The IP67 seal is achieved when the connector is properly crimped to a 2.5–6 mm² solar cable; the rating does not apply to a partially-mated or improperly-crimped joint.
Technical Specifications
The defining parameters are the 1000 V DC / 30 A rating, the IP67 environmental seal, and the UL94-V0 housing flame rating. Full specs below.
| Parameter | Value |
|---|---|
| Rated voltage | 1000 V DC |
| Rated current | 30 A |
| Compatible cable size | 2.5 mm² to 6 mm² solar cable (approximately 14 AWG to 10 AWG) |
| Environmental rating | IP67 (dust-tight, immersion to 1 m for 30 min) |
| Operating temperature | -40 °C to +85 °C (-40 °F to +185 °F) |
| Contact material | Tinned copper |
| Housing material | PPE (polyphenylene ether) |
| Flammability rating | UL94-V0 |
| Insertion force | ≤ 50 N |
| Withdrawal force | ≥ 50 N |
| Compliance | RoHS compliant |
| Internal SKU | 54G-CON-PV-001 |
Technical data sourced from manufacturer documentation.
What's Included
- 1 x male PV connector body with tinned copper contact
- 1 x female PV connector body with tinned copper contact
Crimping tool not included. Use a PV-rated crimping tool sized for 2.5–6 mm² contacts.
Compatibility & Applications
This pair is mechanically and electrically compatible with the standard PV connector form factor used industry-wide and pairs with most equivalent connectors from other manufacturers. Typical applications include:
- Residential rooftop solar panel interconnects
- RV, caravan, van, and boat solar installations
- Off-grid cabin and remote-monitoring PV systems
- Mobile and portable solar charging stations
- Solar charge controller input wiring
Not compatible with: cables outside the 2.5–6 mm² range (won't crimp securely), AC household wiring (not rated for AC use), and any application above 1000 V DC or 30 A continuous.
