1000w flexible solar panel 12v 24v panel solar 100w monocrystalline battery charger for rv electric car camping yacht
1000w flexible solar panel 12v 24v panel solar 100w monocrystalline battery charger for rv electric car camping yacht
Couldn't load pickup availability
SPECIFICATIONS
is_customized: Yes
Type: Solar Panel
Size: 1050*530*2.5mm
Origin: CN(Origin)
Number of Panels: >20
Number of Cells: 32
Nominal Capacity: 100w
Model Number: RGN32-100
Max. Power: 100w
Material: Monocrystalline Silicon
Foldable Solar Panel: No
Flexible Solar Panel: Yes
Certification: RoHS
Certification: CE
Brand Name: dgsunlight
Electrical Characteristics |
Thermal Characteristics |
||
Max Power Pmax |
100W |
Temperature coefficient of Pmax |
-0.38%/℃ |
Max Power voltage Vmp |
16V |
Temperature coefficient of Voc |
-60.5mV/℃ |
Max Power Current Imp |
6.25A |
Temperature coefficient of Isc |
2.2mA/℃ |
Open Circuit Voltage Voc |
19.2V |
NOTC |
47℃+/-2℃ |
Short Circuit Current Isc |
6.68A |
Operating Temperature |
-20℃ - +65℃ |
Maximum System Voltage |
700V |
Mechanical Characteristics |
|
Number of cells in Series |
32 |
Dimension |
1050X530X2.5mm |
Cell size |
125X125mm |
Weight |
1.9kg |
Max Power tolerance |
±3% |
Cable |
0.9 meter 2X2.5mm |
Advantages
Super Lightweight: With polymer materials, this product weighs 70% less than conventional solar panels, making transportation and installation a breeze.
High Efficient: High efficiency solar cell: Monocrystalline 21%.
Extremely Flexible: This panel is capable of
meeting a wide range of applications where standard panels can be inconvenient to mount, such as on the curved roof of an airstream.
Super Thin: Hardly noticeable, the 100W Lightweight Panel laid flat is only a tenth of an inch tall! Approximately 95% thinner than its rigid counterpart, this panel is ideal for a stealthy solar setup.
Protection: Bypass diodes minimize power drop caused by shade and ensure excellent performance in low-light environments.
Highly Durable: Rigorously tested, the 100W panel was designed to withstand extreme wind and snow loads and marine environment.
Easy to install: Metal holes in the corners of the product for fixing screws and mounting.
