100A Tuya WiFi Smart Single Phase Energy Meter Over Under Voltage Protector Electricity Bi-Directional Measure kWh Power Meter

100A Tuya WiFi Smart Single Phase Energy Meter Over Under Voltage Protector Electricity Bi-Directional Measure kWh Power Meter

Regular price $40.80 USD
Regular price $0.00 USD Sale price $40.80 USD
Sale Sold out
Shipping calculated at checkout.
Default Title

This 100A Tuya WiFi Smart Single Phase Energy Meter is the perfect solution for monitoring and protecting your electricity usage. With over and under voltage protection, bi-directional measurements, and WiFi connectivity, this meter provides accurate kWh power readings for enhanced energy management.

SPECIFICATIONS

  • Brand Name: EARUELETRIC
  • DIY Supplies: ELECTRICAL
  • Display Type: LCD
  • Output Voltage: AC110V/220V
  • Model Number: EAEMP1-100TY-W
  • Power Supply: AC
  • Phase: single phase
  • Rated Voltage: 230V
  • Dimensions: 93*78*78mm
  • Operating Temperature: -30℃ to 70℃
  • Accuracy Class: 1%
  • Max Operating Current: 80A - 99A
  • Operation Voltage Range: AC80V-400V
  • Current Limit Protection: 1-100V(adjustable)
  • Over Voltage: 120V-300(adjustable)
  • Under Voltage: 80-210V(adjustable)
  • Reconnect Times(Delay Time): 10s-99s(adjustable)
  • Over Current and Leakage Reconnect Times: 1-30/Off(adjustable)
  • Temperature Protection: 10℃-85℃(adjustable)
  • Timing Modes 1: Schedule Mode
  • Timing Modes 2: Countdown Mode
  • Timing Modes 3: Cycle Timing
  • Timing Modes 4: inching Mode

Our factory can provide OEM service to manufacture this device with your brand, logo, if you get any need, feel free to contact the buyer!

Product specification

  • Rated voltage: AC110/230V; Frequency: 50Hz/60HZ

Function:

  • Under Voltage Protection 80V-210V (adjustable) (default: 175V)
  • Over Voltage Proteciton 120V-300V (adjustable) (default: 275V)
  • Over Current Protection 1A-100A (adjustable) (default: 100A)
  • Reconnect Time (Delay on Time): 10s-90s (default: 30s)
  • Power Display Range:0-99999.9kWh
  • Temperature Protection:10-85℃(Adjustable)
  • Over Current and Leakage Reconnect Times:1-30/OFF(Adjustable)(default:5)
  • Four Timing Modes:Schedule Mode/Countdown Mode/Cycle Timing/Inching Mode

NOTE :If the protector trips three times due to leakage  protection, the device will no longer be reconnected automatically again until the user has checked where is the power failure and fixed it to make sure the people safety! Other protection and reconnecting can cycle for over 99999 times.

PS: This device has memory function, when the power is cut off, the device can memory the Kwh, over voltage, under voltage and over current value.
