10KW Vertical Axis Wind Turbine Generator — CE Certified | MPPT Controller | 12V to 230V
A CE-certified 10,000W vertical axis wind turbine (VAWT) built for residential off-grid, hybrid solar-wind, and remote energy systems. Available in 7 voltage configurations from 12V to 230V, it includes an MPPT (Maximum Power Point Tracking) hybrid controller that accepts supplemental solar input up to 1,000W — enabling a complete wind-solar charging system from a single unit. With a permanent magnet AC generator, cast aluminium alloy body, and 2-blade aerodynamic design, this turbine starts generating power at low wind speeds and operates reliably in variable wind conditions.
Product Description
The 10KW VAWT from 54 Energy captures wind energy from any direction without needing to rotate toward the wind source — a key advantage over horizontal axis turbines in urban rooftops, coastal sites, and locations with turbulent or variable wind patterns. The patented permanent magnet AC generator delivers low-torque, high-efficiency energy conversion, while the dual-bearing cast aluminium alloy body ensures structural durability in outdoor installations. Output is routed through the included MPPT hybrid controller, which automatically detects 24V or 48V battery bank configurations and manages charge cycles to maximize energy yield. The controller also supports up to 1,000W of solar panel input (200W default), making it a practical foundation for a hybrid renewable energy system without additional charge controller hardware.
Key Features & Benefits
- ⚡ 10,000W rated output — sufficient to power a medium off-grid home or supplement grid-tied consumption
- 🔄 Omnidirectional wind capture — no yaw mechanism required; effective in variable and turbulent wind
- ☀️ Hybrid MPPT controller included — accepts up to 1,000W solar input alongside wind generation
- 🔋 7 voltage options (12V / 24V / 48V / 96V / 110V / 220V / 230V) — compatible with most battery banks and inverters
- 🏗️ Cast aluminium alloy body with dual bearings — corrosion-resistant, low maintenance, long service life
- ✅ CE certified — meets European safety, health, and environmental protection standards
- 📡 TL232 interface on controller — enables parameter monitoring via USB adapter (optional)
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Power | 10,000W (10KW) |
| Turbine Type | Vertical Axis Wind Turbine (VAWT) |
| Voltage Options | 12V / 24V / 48V / 96V / 110V / 220V / 230V |
| Number of Blades | 2 — precision injection-moulded, aerodynamic profile |
| Generator Type | Patented permanent magnet AC generator |
| Body Material | Cast aluminium alloy with dual bearings |
| Shaft Material | Iron |
| Mounting Type | Tube or flange connection (base not included) |
| Certification | CE |
| Controller Included | Yes — MPPT Hybrid Controller |
| Solar Panel Input (Controller) | Default 200W — expandable to 1,000W |
| Voltage Recognition (Controller) | 24V / 48V auto-detect or 48V fixed |
| DC Outputs (Controller) | 2 × 12A |
| Controller Interface | TL232 port (USB adapter optional) |
What's Included
- 1 × 10KW Vertical Axis Wind Turbine (VAWT) unit
- 1 × MPPT Hybrid Controller (wind + solar input)
- Mounting hardware for tube or flange connection
Note: Mounting base, pole, and solar panels are not included.
Compatibility & Applications
This turbine is compatible with 12V to 230V battery banks and off-grid inverters. The 48V configuration is the most widely used for residential hybrid solar-wind systems. The 110V variant suits North American grid-compatible setups, while 220V and 230V serve European and UK standard systems respectively.
- Off-grid residential wind energy systems
- Hybrid wind + solar battery charging installations
- Remote farms, rural properties, and cabins
- Coastal and marine wind power applications
- Supplemental energy generation for grid-tied properties
- Industrial and agricultural off-grid power supply
Certifications
This turbine carries CE certification, confirming compliance with European Union directives on safety, electromagnetic compatibility, and environmental protection. CE compliance is verified against manufacturer documentation as part of 54 Energy's product sourcing process. No additional certifications are claimed beyond those documented by the manufacturer.
Frequently Asked Questions
What is a vertical axis wind turbine and why consider one?
A vertical axis wind turbine (VAWT) generates electricity from wind regardless of wind direction, unlike horizontal axis turbines that must face the wind. This makes VAWTs better suited for rooftops, urban environments, and sites with variable or turbulent wind — where a horizontal turbine would lose significant efficiency.
Which voltage configuration should I choose for my system?
Choose based on your battery bank or inverter voltage. 48V is the most common for residential off-grid and hybrid solar-wind systems. 12V and 24V suit smaller installations and caravans. 96V works for medium-scale industrial battery banks. 110V, 220V, and 230V are for systems feeding directly into grid-compatible inverters at those standards.
Does this turbine include a mounting base or pole?
No. The turbine connects via tube or flange fitting and does not include a mounting base or pole. The connection type is selected at installation based on your mounting structure and site requirements. Contact info@54energy.net for guidance on compatible mounting solutions.
Can I connect solar panels to the included MPPT controller?
Yes. The MPPT hybrid controller supports solar panel input — 200W by default, expandable to 1,000W. This enables a combined wind and solar charging system using a single controller, reducing hardware costs and installation complexity for hybrid off-grid setups.
How does this 10KW VAWT compare to a 5KW model for home use?
A 10KW turbine produces approximately twice the rated output of a 5KW unit under the same wind conditions, making it suitable for larger homes, farms, or systems with higher energy demand. A 5KW unit is typically sufficient for a small off-grid cabin or supplemental charging. Choose 10KW if your average daily consumption exceeds 20–30kWh.
Is this turbine CE certified?
Yes. This turbine carries CE certification, meeting European safety, health, and environmental protection standards. CE compliance is verified as part of our product sourcing review process at 54 Energy. Only manufacturer-documented certifications are listed.
Can I request a quote or estimate?
No need to request quotes or estimates. You can purchase all products online directly on our website at 54energy.net. All pricing is displayed on the product page and checkout is available immediately.
What are the shipping options and delivery timeframes?
We ship to over 33 countries including the UK, USA, Canada, Australia, and most of Western Europe. Delivery typically takes 5 to 15 business days depending on destination. A tracking number is provided after dispatch. Exact timeframes vary by location and are confirmed at checkout.
What wind speed is required to start generating power?
The cut-in wind speed for this turbine is not specified in the manufacturer's documentation for this model. As a general reference, most 10KW VAWTs begin generating usable power at wind speeds of 2–3 m/s (4.5–6.7 mph). Contact info@54energy.net for model-specific cut-in speed data before purchasing for low-wind sites.
