EV CHARGER 16/32A 1/ 3 Phase 80V 7K/11/22KW with EV Car Type1 and 2 Charger For Volkswagen ID 3/4/5 2006 2010-2022

EV CHARGER 16/32A 1/ 3 Phase 80V 7K/11/22KW with EV Car Type1 and 2 Charger For Volkswagen ID 3/4/5 2006 2010-2022

Regular price $495.20 USD
Regular price $309.50 USD Sale price $495.20 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

Shipping & Returns

The shipping cost varies between $ 0 and 29 USD. The shipping cost is calculated at checkout.

Color

SPECIFICATIONS

suitable for socket: IEC 62196 Type 2

suitable for socket: SAE J1772 Type 1

Wire Diameter: 5*6mm^2+1*0.5mm^2

Warranty: 3 Year

Voltage: 350-390V

Volkswagen VW Model: ID5 2013-2022

Volkswagen VW Model: ID4 2013-2022

Volkswagen VW Model: ID3 2011-2022

Suitable Capacity: 7KW 11KW 22KW

Plug Type: Type 2

Placement on Vehicle: FRONT

Other Part Number: IEC 62196-2

Origin: CN(Origin)

Operating temperature: -30℃ to 55℃

Material Type: ABS

Item Weight: 5.5KG

Item Length: 31CM

Item Height: 16.1CM

Input Current: 24-32A

For Vehicle Brands/Model: Volkswagen VW

Degree of protection: IP65

Country/Region of Manufacture: CHINA

Cord Length: 6-10m

Color: black

Charger Type: Charging Station

AC Power Supply: 3 Phase

7KW Per Hour Charge/km: 50km/Per Hour

7KW: 32A 1 Phase 7KW

22KW Per Hour Charge/km: 110km/Per Hour

22KW: 32A 3Phase 22KW

11KW Per Hour Charge/km: 80km/Per Hour

11KW: 16A 3 Phase 11KW

Input & Output



Input voltage/Output voltage
220V-240V 380-400V
Max. output current

16A 32A

Max. output power
7KW 11KW 22KW
  SAE J1772-1,  IEC 62196-2
Protection



Over voltage protection
YES
Earth leakage protection
YES
Under voltage protection
YES
Over-temp protection
YES
Over load protection
YES
Lightning protection
YES
Short circuit protection
YES


Working environment



Protection degree
IP65
Maximum altitude
<5000m
Environment temperature
-40℃ ~ +80℃
Cooling
Natural air cooling
Relative humidity
0-95% non-condensing
Standby power consumpiton
<8W
   Brand model
For Volkswagen ID3 ID4 ID5
Years
2004-2022
Certificate
CE, FCC, CSA, IK10, IP66





Control Box Function:

1.Leakage protection (restart recover).

2.Over voltage under-voltage protection (self-checking recover).

3.Lightning protection.

4.Over current protection.

5.Overheat protection.

6.Ground protection.

7.Change the current: 8A/10A/13A/16A/32A

8.RFID card function (Can be set according to user needs)

9.Charging time to make an appointment

10.APP WIFI Version

Please carefully read the list of models you need:

▶ For Volkswagen ID3 EV (2009-2022)
▶ For Volkswagen ID4 EV (2011-2022)
▶ For Volkswagen ID5 EV (2013-2022)
