1P+N Din Rail WIFI Smart Energy Meter Power Consumption kWh Circuit Breaker Time Timer Switch Relay Voltmeter for Smart Home
1P+N Din Rail WIFI Smart Energy Meter Power Consumption kWh Circuit Breaker Time Timer Switch Relay Voltmeter for Smart Home
Regular price
$18.86 USD
Regular price
$0.00 USD
Sale price
$18.86 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
This energy meter is a must-have for smart homes, providing precise power consumption data via WiFi and a convenient timer switch. Its 1P+N din rail design and circuit breaker make it easy to install and use. Monitor and manage energy use with ease using this versatile voltmeter.
SPECIFICATIONS
- Mechanical Life: Over 100000 Times
- Fuction 1: On/off Switch
- Fuction 2: Time Relay Switch
- Fuction 3: Voltmeter
- Fuction 4: Ammeter
- Fuction 5: Power Meter
- Fuction 6: Current Limit
- Working Temperature: -25℃-70℃
- Working Voltage: AC100-240V
- Working Current: 1-63A
- Frequency: 50/60Hz
- Fuction 7: share
- Fuction 8: Remote control Any where
- Fuction 9: Voice Control
- APP: eWeLink
- Brand Name: EARUELETRIC
- Model Number: RDCBC2/RDCBCL
- Type: Mini
- Rated Voltage: 220V
- Is Smart Device: YES
- Type: Circuit breaker
1P Din Rail WIFI Smart Energy Meter Power Consumption kWh Meter Circuit Breaker Time Timer Switch Relay Voltmeter for Smart Home We can offer OEM service to print your logo on the circuit breaker, if you get any need, feel free to contact the seller!
Function:
- On/off Switch
- Time Relay Switch
- Voltmeter
- Ammeter
- Power Meter
- Current Limit
- Over current protection(0.1~63A), over voltage protection(0.1~1000V), Max power protection(10~500000w), min power protection(0.1~3300w).
- Leakage Protection:30mA(upport only:RDCBC2)
Features
- Remote control at anytime from anywhere
- Schedule/Timer/loop timer
- Energy monitoring,Set power unit price ,can caculate house device power consumption,Download data to sheet
- Preset power/current/voltage threshold values by app, Once the real-time power/current/voltage reaches the threshold values, The connected electrical appliances will be automatically turned off
- Power on reaction: after the equipment is powered off and powered on again, the product can return to the state before power on,the device can also be set to the ON or OFF state after power on.
- Working Voltage: AC100-240V
- Mechanical Life: Over 100000 Times
- Working Temperature: -25℃-70℃
