5000W Peak Off Grid Pure Sine Wave Solar Inverter 2500W 12V/24V DC to 120V/220V/230V/240V DC/AC Car Power Inverter Hybrid Inverter LCD Display With 30A Solar Controller Charger

Different dc voltage and ac voltage can be customized! Please leave me a messages of your specifications:

Leave me all these specifications by sending me a message, so that I can make sure of a fast shipping!

About us:

-Our company is the leading and professional manufacturer for 150w to 10000w DC TO AC OFF GRID PURE SINE WAVE INVERTER and grid the inverter from 200W to 2000W. Our professional technical department, will support the best technical service and after-sale technical service.

-Our principle is “quality first, customer priority, service best, trade honest”.

-With the high quality, favorable fame, excellent service, our power inverters are sold all over the world. We have many loyal customer in the Europe, America, Asia, etc.

-All inverters are stricktly inspected before leaving factory, Reliable Company Guarantees that each inverter is in its best operating condition.

About the advantage:

-100% true sine wave output, Full power guaranteed.

-100% New Electric Components, Double-side PCB and imported Mexico FAIRCHILD MOSFET and Nippon ChemiCon Capacity.

-The wider case, the better for heat dissipation.

-Every component is distributed to rationality, greatly improving the reliability and service life of the inverter.

-All around protection greatly reduce the possibility of damage.

Application:

-Energy system: Solar energy source system, Wind energy source system, Car system, etc.

-Office Equipment: PC, Laptop, Printer,etc.

-Home Appliance: TV, Air conditioner, Oven, Cooker, DVD, GPS Fridge, Cleaner, Washer, Fan, Light, Refrigerator, etc.

-Industrial Equipment: Pump, Compressor, Motor, etc.

Product Detail Parameters：

DC Voltage	12V or 24V or 36V or 48V
Voltage Range	10-15VDC or 21-30VDC or 42-60VDC
NO Load Current Draw	<1A
Efficiency	>90%
DC Connector	Cables With Clips or Car Adaptor
AC Voltage	100/110/120VDC /AC or 220/230/240VDC /AC
Continuous Power	2500W
Surge Power	5000W
Waveform	Pure Sine Wave
Frequency	50HZ or 60HZ
AC Regulation	3%
Low Voltage Alarm	10DC±0.5V or 20.5DC±1V or 44VDC±1V
Low Voltage Shut Down	9.5DC±0.5V or 19.5DC±1V or 42VDC±1V
Over Load	Shut Off Output
Over Voltage Shut Down	15.5V or 30.5V or 61.2V
Over Thermal	Shut Off Output Automatically
Fuses	Short Circuit
Working Temperature	Between -10centi and +50centi
Working Humidity	20%~90%RH non-condensing
Storage Temperature	Between -30centi and +70centi
Start	Soft Start
Cooling Ways	Cooling Fan
Total Harmonic Distortion THD	<5%
Machine Size(mm)	350*240*220
Packing Size(mm)	470*300*250
Net Weight(kgs)	6.5KG
Gross Weight(kgs)	9KG
Packing Type	Carton Packing

Solar Charger Detail Parameters
Rated Current	30A
Rated Voltage	12V/24V
Open Circuit Voltage of solar panel	≤50V
Low Voltage Disconnection(LVD)	10.7V/21.4V
Float Voltage	13.8V/27.6V
Low Voltage Reconnection(LVR)	12.5V/25.0V
No load loss	≤30mA
Loop Voltage Drop	≤170mV
Charging Mode	PWM mode
Temperature Compensation	-4mV/Cell/C

Product Details:

Protection Systems：

Thermal protection, Overload protection, Over Voltage protection, Under Voltage protection, Low Voltage protection alarm. Inverter comes with an LED light to indicate the problem.

9 kinds of protections:

1.Short circuit production.

When the load is short circuit, the inverter will stop working.

2. High temperature production.

When the use environment is stuffy, the heat of the inverter can not be radiated. The temperature is above the rated temperature, the inverter will stop working.

3. High voltage protections.

The battery voltage is above the rated voltage of the inverter, the inverter will stop working.

4. Low voltage protections

The battery voltage falls during the usage. When it is lower than the rated voltage, the inverter will automatically cut the input voltage for the self protection.

5. Surge protection.

It can avoid the DC high voltage surging attack upon the electronic components inside.

6. Overload protection

When the appliances power is higher than the inverters power, the inverter will stop working for self protection.

7. Over current Protection

When the appliances current is  bigger than the inverter™ current, the protection components on the board will be cut automatically for self protection.

8.Fuse protection.

When the appliances resistance is bigger than inverters, the fuses on the socket will be automatically cut off for self protection.

9. Reverse protection

It can avoid the accidents of burning the inverter if the positive and the negative poles are reverse connected.

The Resistive Load Applications and  The Inductive Load Applications:

For resistive load applications:
If you need the inverter to run the resistive load (like laptop, TV, electric cooker, LED light), please choose the inverter with continuous power higher than the appliance's rated power.For example, for the power inverter with continuous power 2500w,it is suggested to run the appliance with rated power less than 2500w. It is best to use 80% of the rated power.

For inductive load applications:
If you need the inverter to run the inductive load (for appliance such as compressor, motor, water pump), please calculate the power of inverter 3 to 7 times higher than the rated power of your appliance.

Product Certification:

Durable and safe quality with many years usage, our pure sine wave inverters are approved by EMC testing in Australia and CE certified. 18 months warranty.

The Packaging:

The Transportation:

For the small capacity, The inverter will be sent by DHL, EMS, Fedex and TNT, it  will take 3-9 days for shipping.

If you have any question in the transport process, please contact with me in time.

Customer Service:

-18 months warranty.

- Please leave me the message about the DC input,  AC output, the frequency and the socket type before shipping, I will confirm for you. If the package is returned for customer's fault, the customer need to pay for additional fee, if not, we will pay for additional fee and send the right one at once.

- Please attention if the package is broken before you received it, please don't open the package and show me the photo, I will contact with the express at once.

- If you have any question when you use the inverter, please feel free contact with me, the professional technical  department will help you to deal with the problem.

FAQ:

Q 1. what's the payment term?

A. You can make a payment online, the TT, PayPal ,Western Uninon is also accepted.

Q 2. how's the delivery time ?

A. Sample will be sent in 3 days, big order according to the quantity , 2 weeks at most.

Q 3. tell me the standard of package?

A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.

Q 4. what kind of material of transformer?

A. We use 100% copper

Q 5.Could you offer Form A or C/O ?

A. Really no problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.

Q 6.Would you accept to use our logo ?

A.If you have good quantity,absolutely no problem to do OEM.

Q 7.Could you accept the customized inverter ?

A. Yes, we accept the customizing inverter, such as print the logo in the shell, change the color of the shell.

Q 8.Where is your market?

A. We have been doing Europe, Russia , America ,Brazil ,Australia market for about 8 years , reliable quality make our business last long

Q 9.Does the inverter connect with solar/wind system ?

A.Yes. we have both off grid and on grid pure sine wave inverter

Q10. what kind of certificate you have ?

A. Our company already achieve CE , EMC certification .
