AT4PW 100A Tuya WIFI Din Rail Smart Switch Remote Control AC 220V 110V Digital Power Energy Volt Amp Kwh Frequency Factor Meter

4.9 ( 20 reviews )

$56.38 USD

~~$0.00 USD~~ $56.38 USD

Sale Sold out

Shipping calculated at checkout.

Color WiFi Rail Meter 100A

Quantity

Monitor and manage your power usage with the AT4PW 100A Tuya WIFI Din Rail Smart Switch. Connect to your AC 220V or 110V system through remote control, and track energy consumption in real-time with digital power, voltage, amperage, and frequency measurements. Make smart decisions to save energy and reduce costs.

SPECIFICATIONS

Installation: 35mm Din rail
Display Panel: 2.4 inches TFT-LCD HD Display Panel Graphic 240*320 RGB Dot-matrix
Wireless Type: 2.4GHz 802.11b/g/n
Power range: Max 26.5KW
Energy Measurement range: 0~99999 kWh
Brand Name: EARUELETRIC
Power Supply: AC
Model Number: AT4PW
Display Type: LCD
Accuracy Class: 1%
Dimensions: 76*76*97mm
Rated Voltage: 220V
Operating Temperature: -20°C~+60°C
EARUELETRIC Model: AT4Pw
Measuring Energy Range: 0-99999kWh
Phase: single phase
Max Operating Current: 80A - 99A
Output Voltage: AC85-265V
Certification: RoHS
DIY Supplies: ELECTRICAL

Firmware Upgrade Notice

Short press the "+" key button or "-" key button to switch the function interface
Long press the "+" key button or "-" key button to turn on or turn off the device

2.4 # TFT HD Color Display Guide rail type smart meters (Display Panel:2.4 inches TFT-LCD HD Display Panel Graphic 240X320 RGB Dot-matrix)
