Wind Turbine 20KW Horizontal Power Generator 220V/380V Wind Mill Yawing Home Use, Grid Tie / Off-Grid Use

Wind Turbine 20KW Horizontal Power Generator 220V/380V Wind Mill Yawing Home Use, Grid Tie / Off-Grid Use

Regular price $83,229.00 USD
Regular price $0.00 USD Sale price $83,229.00 USD
Sale Sold out
Shipping calculated at checkout.
Voltage
Specification
Color|Wattage

SPECIFICATIONS


wheel diameter: 10m

speed regulation: Automatically adjust windward direction

rated wind speed: 10m/s

rated voltage: 220V/380V

rated power: 20KW 150RPM

is_customized: Yes

generator: 3phase ac PMG

blades: 3

Type: Wind Power Generator

Shaft Material: IRON

Origin: CN(Origin)

Mounting Base: With Mounting Base

Model Number: AMG20KW150RPM

IP: 65

Gross Weight: 1240KG

Certification: CE

Brand Name: AMG POWER SOLUTIONS


Shortcut to SC series wind turbines:

500W1KW2KW3KW5KW10KW20KW

Shortcut to SC series PMG generators:

500W1KW2KW3KW5KW10KW20KW


1..The price displayed here is just for refference. Please contact me to get the accurate price.


2.. Due to the big size and weight, air fregiht is too expensive. It's better to ship by sea. Some countries could be shipped to by truck or train in a duty free way. Please contact the seller if you are interested.


3.. The price and the package doesn't include the standing pole or tower. If you need the standing pole or tower, please contact the seller.


4.. "Controller brade" means you need to buy a controller or any other device with braking function, then the turbiune could be braked by the controller when the battery is full or the wind speed reaches its limit.




Rated power

500W

1KW

2KW

3KW

5KW

10KW

20KW

Wheel diameter

2.5m

2.8m

3.2m

4m

5m

7m

10m

Blades material

Fiberglass-ReinforcedPlastic

Rated speed

8m/s

9m/s

9m/s

9m/s

10m/s

10m/s

10m/s

Rated Power

500W

1000W

2KW

3000W

5KW

10KW

20KW

Max Power

750W

1500W

3KW

4.5W

7.5KW

15KW

30KW

Rated voltage

220V

220V

220V

220V

220V

380V

380V

Start wind speed

3m/s

3m/s

3m/s

3m/s

3m/s

3m/s

3m/s

Rated RPM

400

380

380

300

260

200

150

Woking wind speed

3.0-20m/s

3.0-20m/s

3.0-20m/s

3.0-20m/s

3.0-25m/s

3.0-30m/s

3.0-30m/s

Safety wind speed

35m/s

40m/s

35m/s

35m/s

40m/s

45m/s

45m/s

Speed regulation

method

Controller bake

Controller brade + yawing

Brake method

Controller bake

Controller brake + manual brake

Generator type

3-phase AC PMG

Body weight

45kg

56kg

68kg

120kg

320kg

650kg

1150kg

Recommended

controller capacity

24V50A

48V60A

48V100A

48V100A

240V100A

500V100A

500V200A

Recommended

battery volume

12v150AH

*2pcs

12v150AH

*4pcs

12v200AH

*4pcs

12v200AH

*4pcs

12v150AH

*20pcs

12v150AH

*40pcs

12v200AH

*40pcs











Generator adopted:
